Planet 2-Port Combo PS/2/USB KVM Switch / KVM-210 :: Detalle de Producto :: PLANET Combo KVM switches are designed to give you the control of multiple computers using just one keyboard, mouse and VGA monitor. The new Combo KVM switch also shares microphones and speakers to all the connected PCs. They provide more space in addition to saving the cost of multiple keyboards, mice and monitors. Switch between computers by just pressing a button on the panel or predefined Hot Key on connected keyboard. The KVM Switch series are the perfect choice for home, office, server farm, or testing sites so that users can manage multiple computers efficiently and easily.
| Model |
KVM-210 |
| Product |
| Computer Port |
VGA ports
2 Microphone ports
2 Speaker ports |
| Console Port |
1 PS/2 keyboard port
1 PS/2 mouse port
1 VGA port
1 Microphone
port
1 Speaker port |
| Computer Port Connector |
Keyboard: PS/2 Mini DIN 6-pin female and USB Type-B connector
Mouse: PS/2
Mini DIN 6-pin female and USB Type-B connector
Monitor: HDDB 15 pin
female
Microphone: Audio female jack
Speaker: Audio female jack |
| Console Port Connector |
Keyboard: PS/2 Mini DIN 6-pin female
Mouse: PS/2 Mini DIN 6-pin
female
Monitor: HDDB 15 pin female
Microphone: Audio female
jack
Speaker: Audio female jack |
| PC Selection |
Hot Key, Push Button |
| Keyboard Conversion |
PS/2 to PS/2 and USB |
| Mouse Conversion |
PS/2 to PS/2 and USB |
| Video Resolution |
2048 x 1536 |
| Housing |
Metal |
| Power Type |
Bus Power |
| Power Adapter (Optional) |
DC 5V, 2A |
| Operating Temperature |
0 ~ 50 Degree C |
| Storage Temperature |
-20 ~ 60 Degree C |
| Humidity |
0 ~ 80% RH non-condensing |
| Dimension (W x D x H) |
140 x 85 x 45 mm
|
| Weight (g) |
460
|
|
