Planet 48-Port 10/100 + 4 Gigabit TP/2-Port mini-GBIC Layer 3+Switch/WGS3-5220 :: Detalle de Producto :: The PLANET WGS3-5220 is a 48-Port 10/100Mbps Layer 3 Managed Ethernet Switch. It essentials Layer 3 functionality of multimedia switch that brings high-end security and traffic control to the edge of the network. With IP routing capability and flexible managed tools, the PLANET Managed Multi-Layer Switch Solution performs a cost-effective way for today with the ability to expend as the growing of network demands.
Layer 2 Features
• The
10 / 100Base-TX ports support auto-sensing and auto-negotiation
• Supports
Jumbo frame up to 9K Bytes on 10 / 100 / 1000Base-T ports
• Provides wire
speed of L2 switch performance
• Supports up to 16K MAC address entries
• IEEE 802.3x Flow Control for Full-Duplex mode and Back-Pressure in
Half-Duplex mode
• Provides Store-and-Forward scheme
• Provides
Broadcast storm protection
• Supports IGMP snooping v1, v2 and V3
•
Supports 802.1Q Tagged VLAN, Protocol-Based VLAN and GVRP protocol for
dynamic VLAN Management
• Supports double-tagged for Q-in-Q VLAN tag
frame
• Supports Spanning Tree Protocol with 802.1d STP, 802.1w RSTP and
802.1s MSTP
• Link Aggregation bandwidth gathering supports 802.3ad LACP and
Static Port Trunk
• Provides Port Mirror (many-to-1)
IP Routing
Features
• IP Routing protocol supports RIP v1 / v2, OSPF v2
•
Routing interface provides per Port routing and VLAN routing mode
• Supports
router discovery (IRDP)
• VRRP protocol for redundant routing deploy
•
Supports route redistribution
Multicast Routing Features
•
Supports PIM-DM and PIM-SM
• Supports DVMRP
• Supports IGMP v1 / v2 /
v3
Security
• User / Password protected system management
• L2 / L3 / L4 ACL (Access Control Llist)
• RADIUS and TACACS client
• IEEE 802.1x Port-Based Authentication for network access control
•
Port MAC lock security
Quality of Service
• IEEE 802.1p based
on CoS
• IP TOS / Precedence and DSCP based on CoS
• 8 priority queues
per port
• Policy based on DiffServ per port
• Supports for strict
priority and weighted round robin (WRR) CoS policies
Management
• Provides 1 male DB9 RS-232 console interface
• Supports Command Line
Interface of switch management
• Supports Web management of switch
•
Supports SNMP v1, v2c, and v3 switch management
• Supports BOOTP and DHCP
for IP address assignment
• Supports DHCP Server function
• Supports
software and configuration upload / download via XMODEM or TFTP
• Supports
SSH v1 / v2 and SSL v3 / TLS v1 switch management and login to
security
network
• Supports SSH / SSL / TLS keys downloaded via XMODEM or TFTP
•
Supports SNTP (Simple Network Time Protocol)
• Supports Ping and telnet
functions
• Supports message / event / error / trap logs
• Supports
logging to local files and syslog servers
• Supports Private Enterprise
MIB
• Supports RMON groups 1, 2, 3, 9
|
