Planet Print Server 2 USB/1 Paralelo/FPS-3121 :: Detalle de Producto :: Equipped with the USB & Parallel printing interfaces, the Multi-Port Print
Server makes your printer sharing available in the most popular wired and
wireless network environments. With the embedded web server, the Print
Servers are configurable through your network. Moreover, PLANET also provides a
management utility for Microsoft Windows systems. With various network printing
methods including Windows Peer-to-Peer printing, NetWare and Windows server
based Queues printing, LPR printing, Internet Printing Protocol (IPP) and
AppleTalk for Macintosh, the Print Server can be applied to any network easily.
• Supports for most popular
NOS
–Supports NetWare, Windows 98/NT/2000/Me/XP/Server 2003, Linux, Unix,
Apple
Ethernet Talk
• Auto-Sensing
–Supports 10/100Mbps
Auto-Nway, Automatically Negotiates optimal mode, 10/20Mbps,
100/200Mbps
–Ethernet 802.2, Ethernet 802.3, SNAP Auto-Detect
• Auto-MDI/MDI-X
–Auto detects the connected cable type while
connecting to different LAN devices.
It is capable of detecting the signal
and changes its transfer/receive order on
the cable
automatically.
• Supports up to 7 logical printers for TCP/IP
networks
–Handles up to 7 logical printers, users can easily redirect to
their own 'name'
printer without confusion
• Compatible with
popular network utility
–Unix, TCP/IP: LPD, TFTP
–Windows: LPR, PTP
driver, IPP, SMB (NetBEUI)
–Apple: Ether Talk Chooser
–NetWare: IPX/SPX,
TCP/IP (5.x and newer)
• Easy Management
–Intuitive management
utility provided for Windows 98/NT/2000/Me/XP and Server
2003
–Web-Base Management
–SNMP Supported
| Model |
FPS-3121 |
| Wired
Interface |
| Media Interface |
1 x RJ-45 UTP |
| Standards |
IEEE802.3, 10Base-T; IEEE802.3u, 100Base-TX; Auto-MDI/MDI-X |
| Cabling |
Category 5/5e or above, 2-pair |
| General
|
| Printer Ports |
1 x Parallel Port + 2 x USB 2.0 |
| Management Tools |
Server Manager (Windows Application), Web-based management (HTTP) |
| Dimension (W x D x H) |
187 x 106 x 30 mm |
| Weight |
265g |
| Power Supply |
12V DC, 1A |
| Emission |
FCC / CE |
|
